SAPF207-20 HLB Stamped Steel Unit
HLB SAPF Stamped Steel 3-Bolt Flange Unit – Eccentric Locking. Shaft diameter: 35 mm (1-1/4 in). Housing dimensions from the supplied catalog: H 122.0 mm, J 100.0 mm.
Description
HLB SAPF Stamped Steel 3-Bolt Flange Unit – Eccentric Locking. Shaft diameter: 35 mm (1-1/4 in). Housing dimensions from the supplied catalog: H 122.0 mm, J 100.0 mm.
Additional information
| Weight | 0.9 kg |
|---|---|
| Bearing Type | SAPF Stamped Steel 3-Bolt Flange Unit – Eccentric Locking |
| Shaft Diameter | 35 mm (1-1/4 in) |
| Housing L | |
| Housing J | 100 mm |
| Housing H | 122 mm |
| Housing H1 | 5 mm |
| Housing H0 | |
| N | 11 mm |
| A | 20 mm |
| d1 | 55.6 mm |
| B1 | 38.9 mm |
| B | |
| S | 8.5 mm |
| Bolt Size | M10 / 3/8 in |
| Weight | 0.9 kg |
