F100F Tyre Coupling Reverse
HLB F100F flexible tyre coupling, reverse tapered-bore configuration.
Description
HLB Flexible Tyre Coupling Reverse, tapered bore, size F100. Taper-lock bush size 3020. Supplied as the half coupling; tyre element is not included.
Additional information
| Weight | 9.9 kg |
|---|---|
| Size | F100 |
| Power @ 100 rpm | 7.07 |
| Nominal Torque | 675 |
| Max Speed | 2600 |
| Bore Max | 75 |
| Bore Min | 16 |
| Bush Size | 3020 |
| Parallel Misalignment | 2.6 |
| Angular Misalignment | 4 |
| End Float | 3.3 |
| A | 254 |
| C | 216 |
| D | 120 |
| E | 51 |
| F | 62 |
| L | 65 |
| G | 16 |
| J | 48 |
| M | 13.5 |
| Weight | 9.9 |
